GDGRZ--Double jaw oblique pneumatic clamp
Materials
- High-strength alloy steel clamp body
- Hydrogenated nitrile rubber seals
Implementation standards
- ISO 16090-1
- EN 10083-3
- ISO 6358
- ASTM B117
- Sellingpoint
- Product Show
- 3D Preview
- Inquiry
- Related Products
SOVE
The double jaw bevel pneumatic clamp is based on a self-centering bevel wedge force-enhancing structure, which leads the clamping stability in the field of precision machining. Its bidirectional synchronous locking design provides 18kN constant pressure clamping force.
As a multi-field precision positioning platform, it is deeply integrated in the high-rigidity workpiece clamping system for ⚙️machine tool processing (repeat positioning accuracy ±0.002mm), 🤖heavy-load component positioning mechanism for automated assembly (load capacity > 5 tons | vibration resistance frequency > 200Hz), and 🔧flexible positioning fixture for welding production (thermal deformation compensation ±0.01mm), achieving full coverage of cross-process precision positioning.
Description
- Synchronous clamping mechanism.
- Quick response.
- AR=Abrasion Resistance
- IR=Impact Resistance
- OR=Oil Resistance
1. About 3D models and technical parameters:
"If you need to obtain, please contact us by email."
2. About price consultation:
"If you need to obtain, please get in touch with us. We will provide the most suitable quotation plan."
