GBD--Pneumatic expansion inner support jaws

GBD--Pneumatic expansion inner support jaws

Materials

  • 4340 Alloy Steel Expansion Mandrel
  • Beryllium bronze expansion sleeve
  • 6061-T6 aluminum alloy main body

Implementation standards

  • IEC 60204-1
  • ATEX II 2G Ex h IIB T3
  • EN ISO 13849-1 PL e
  • RoHS 3 & REACH Annex XVII
  • Sellingpoint
  • Product Show
  • 3D Preview
  • Inquiry
  • Related Products

SOVE

The pneumatic expansion internal support clamp relies on the multi-layer composite expansion film process and performs excellently in the internal support clamping of thin-walled parts. Its uniform radial expansion design not only achieves 0.02mm inner diameter deformation control, but is also widely used in bearing ring assembly, precision gear positioning, and medical catheter fixation, especially in the case of 0.1mm wall thickness workpiece to maintain ±2μm concentricity.

It is widely used in nano-scale thin-wall turning systems in 🔧precision turning (deformation < 3μm), thermal displacement compensation positioning mechanisms ✈️in aerospace (positioning accuracy ±2μm), and non-contact lens barrel support platforms in 🔬optical devices (surface accuracy λ/20), realizing cross-industry precision manufacturing technology upgrades under extreme working conditions.

Description

  • Two-stage expansion mechanism.
  • Self-locking design.
  • Thin wall applications.
  • HR=Heat Resistance
  • AR = Abrasion Resistance
  • OR=Oil Resistance
  • VR=Vibration Resistance

1. About 3D models and technical parameters:
"If you need to obtain, please contact us by email."

2. About price consultation:
"If you need to obtain, please contact us. We will provide the most suitable quotation plan."
